M
12
x
1
A-coded
Overmoulded Connectors
Female connector axialsingle ended
5- pos.
Shielded
3 m
AWG
24
TPU ULSeries M
12 Bayonet locking
| Product type | Series M12 Bayonet locking |
| Style | Overmoulded Connectors |
| Size A-side | M12x1 |
| Design | single ended |
| Size/Number of positions | 5- pos. |
| Coding | A-coded |
| Type A-side [ Female, Male] | Female connector axial |
| Locking type | M12 Bajonett |
| Length cable/wire | 3 m |
| IP range A-side | IP67 |
| Working voltage signal | 60 V |
| Current rating signal | 4 A at +40°C |
| min. working temperature | -30° C |
| max. working temperature | +70°C |
| Shielding | Shielded |
| Cable quality [e.g. PP, PVC, TPE etc.] | TPU UL |
| Wire cross section | AWG24 |
