T-coded
Overmoulded Connectors
Female connector axialsingle ended
4- pos.
Unshielded
2 m
1,5 mm²PVC
| Style | Overmoulded Connectors |
| Design | single ended |
| Coding | T-coded |
| Type A-side [ Female, Male] | Female connector axial |
| Size A-side | M12x1 |
| Length cable/wire | 2 m |
| Size/Number of positions | 4- pos. |
| Locking type | Screwable |
| Working voltage note | VOLTAGE MAY BE PRESENT ONLY IN MATED CONDITION |
| Recommended torque | 0,6 Nm |
| Working voltage signal | 63 V AC/DC |
| Sealing material | FPM |
| IP rating | IP67 in mated condition |
| Insulation resistance | >=100M Ohm |
| Cable color | Black |
| Cable quality | LiYY |
| Cable quality [e.g. PP, PVC, TPE etc.] | PVC |
| Wire cross section | 1,5 mm² |
| max. working temperature | +80° C |
| Shielding | Unshielded |
| Mating cycles | >=100 |
| Current rating signal | 12 A at +40°C |
| min. working temperature | -30° C |
| Pollution degree | 3/2 |
