A-coded
Overmoulded Connectors
Male connector axial
Double ended
4- pos.
Shielded
AWG
26
| Style | Overmoulded Connectors |
| Design | Double ended |
| Size/Number of positions | 4- pos. |
| Type A-side [ Female, Male] | Male connector axial |
| Coding | A-coded |
| IP range A-side | IP20 |
| Screw connection [e.g. PG9, M16 etc.] | M8x1 |
| Shielding | Shielded |
| Wire cross section | AWG26 |
| min. working temperature | -25° C |
| max. working temperature | +60° C |
| Pollution degree | 3/2 |
| Working voltage signal | 30 V |
| IP rating | IP 20 |
| Current rating signal | 1 A |
| Mating cycles | >=100 |
| Recommended torque | 0,4 Nm |
