Part No: 42-05105
Ürün Kısa Açıklaması
M
8
x
1
A-coded
Male connector axial
Y-Splitter
8-pos.
1
x Male connector M
8
x
1 + 1
x Female connector M
8
x
1
General Data
| Size A-side | M8x1 |
| Design | Y-Splitter |
| Type A-side [ Female, Male] | Male connector axial |
| Size B-side [e.g. M8, M12, 7/8″ etc.] | M8x1 |
| Size/Number of positions | 8-pos. |
| Installation size exit | 1x Male connector M8x1 + 1x Female connector M8x1 |
| Coding | A-coded |
| Pin configuration exit | 8-pos. |
| Type B-side [Female, male] | Female connector axial |
| Configuration A-side | axial |
| Configuration B-side | axial |
Technical Data
No data available.
Material Data
| Insulator material | PA, UL 94 |
| Coupling nut /-screw material | Zinc die cast |
| Coupling nut /-screw plating | Nickel |
| Signal contact material | Copper alloy |
| Plating signal contact (mating area) | Gold over nickel |
