Part No: 3024W7PXK99A10X

D-SUB Combination Standard
24
W
7 [○○○○○○○•••••••••••••••••]Plug
Crimp
Through hole

General Data

Product type	D-SUB Combination Standard
Contact type	Plug
Size/Number of positions	24W7 [○○○○○○○•••••••••••••••••]
Termination signal [e.g. clamp, crimp, solder, SMT]	Crimp
Hardware options termination side	Through hole

Dielectric with standing voltage signal	1000 V
Dielectric with standing voltage power	1000 V
min. working temperature	-55° C
max. working temperature	+125° C
Working voltage signal	250 V
Working voltage power	250 V
Insertion force	107 N
Extraction force	52 N
