Part No: 3003W3PXX49E30X
Ürün Kısa Açıklaması
D-SUB Combination Standard
3
W
3 [○○○]Plug
Threaded rear spacer
M
3
General Data
| Product type | D-SUB Combination Standard |
| Contact type | Plug |
| Size/Number of positions | 3W3 [○○○] |
| Termination power contact | Solder pin straight |
| Hardware options termination side | Threaded rear spacer |
| PCB fastening | PCB-Clip |
| Hardware options mating side | Threaded insert |
| Thread type | M3 |
Technical Data
| min. working temperature | -55° C |
| max. working temperature | +125° C |
| Quality class | Quality class 3 |
| Mating cycles | 50 |
| IP rating | IP 20 |
| Current rating power | 20 A |
| Insertion force | 21 N |
| Extraction force | 21 N |
